DeWalt DW718XPS 305mm Compound Sliding Mitre Saw + XPS 240 Volt DEW718XPS
DeWalt 718 is a cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° - 60° left and 0° - 50° right.
The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications. The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles - Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 345 mm wide.
With new quick release bevel setting provides accurate and simple setting of bevel angles up to 48° left and right.
The DeWalt 718 is compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the jobsite.
Fitted with electronic speed control for adjusting cutting speed when cutting materials other than wood, XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity.
Specifications
Power Input 1600 Watts
Power Output 960 Watts
Blade Speed 1900 - 3400 /min
Blade Diameter 305 mm
Blade Bore 30 mm
Bevel Capacity 48/48 °
Mitre Capacity [right/left] 50/60 °
Cutting Capacity
at 90°/90° (W x H) 327x90 mm
at 90°/90° (W x H) 345x71 mm
at 45°/90° (W x H) 231x90 mm
at 45°/90° (W x H) 241x71 mm
at 90°/45° (W x H) 327x58 mm
at 90°/45° (W x H) 345x48 mm
at 45°/45° 242x52 mm
Max. Depth of Cut [Saws] 163 mm
Weight 24.8 Kg
Depth 470 mm
Length 770 mm
Height 396 mm
Standard Equipment: 60 tooth blade, Blade spanner, Dust bag
DEW718XPS
